Electro-Voice X-Array XF User Manual

X-Array™ Loudspeaker Systems
FIGURE 2a - Xf SYSTEM
TYP
9.0
584.2 mm
(23.00 in.)
353.8 mm
(13.93 in.)
733.2 mm
(28.87 in.)
758.8 mm
(29.88 in.)
C
L
914.4 mm
(36.00 in.)
457.2 mm
(18.00 in.)
384.1 mm
(15.12 in.)
WEIGHT: WITHOUT EXTERNAL RIGGING: 87.1 kg (192 lb)
WITH EXTERNAL RIGGING: 90.2 kg (199 lb)
O
FIGURE 2d - Xds SYSTEM
914.4 mm
(36.00 in.)
WEIGHT: 121 kg (267 lb)
C
L
736.6 mm
(28.98 in.)
758.8 mm
(29.88 in.)
1166 mm
(45.92 in.)
667.2 mm
(26.27 in.)
18°
TYP.
423.3 mm
(16.67 in.)
457.2 mm
(18.00 in.)
FIGURE 2b - Xn SYSTEM
TYP
9.0
584.2 mm
(23.00 in.)
353.8 mm
(13.93 in.)
733.2 mm
(28.87 in.)
758.8 mm
(29.88 in.)
914.4 mm
(36.00 in.)
441.3 mm
(17.38 in.)
409.2 mm
(16.11 in.)
C
L
WEIGHT: WITHOUT EXTERNAL RIGGING: 87.1 kg (192 lb)
WITH EXTERNAL RIGGING: 90.2 kg (199 lb)
O
FIGURE 2c - Xb SYSTEM
TYP
9.0
584.2 mm
(23.00 in.)
353.8 mm
(13.93 in.)
733.2 mm
(28.87 in.)
758.8 mm
(29.88 in.)
C
L
914.4 mm
(36.00 in.)
457.2 mm
(18.00 in.)
438.5 mm
(17.26 in.)
WEIGHT: WITHOUT EXTERNAL RIGGING: 83.5 kg (184 lb)
WITH EXTERNAL RIGGING: 86.6 kg (191 lb)
O
FIGURE 2 - X-ARRAY LOUDSPEAKER SYSTEMS
page 3
WEIGHT: 87.1 kg (192 lb)
WEIGHT: 87.1 kg (192 lb)
WEIGHT: 83.5 kg (184 lb)
