Service Diagnostics
• Rotate the cycle selector knob clockwise from the starting position
• 0 turns: All LED’s will flash.
• 1 turn: Drive motor runs; heat source is on. Drying LED is lit. “H” and the
control thermistor reading will toggle back and forth in the display.
• 2 turns: Drive motor runs; heat source is off. Cool Down LED is lit and “AF”
(Air Fluff) is displayed.
• 3 turns: Drive motor runs; heat source is off. Drying and Cool Down LED’s
are lit and numbers appear in the display showing moisture sensor
readings. Opening the door (press in on door switch plunger) and placing a
finger on the both moisture sense bars at the same time will make the
numbers decrease. In controls that do not have a digit display, the More
Dry LED should be ON. Opening the door (press in on door switch plunger)
and placing a finger on the both moisture sense bars at the same time will
make the Damp LED come on.
