S31EUK4090SY(2)99-01
Enable the brush motors by pressing the
corresponding button: the brush motors will work
for a few seconds.
Press one time the button for the selection of the
display data: the current brush pressure will be
shown.
Choose the value 50% (i.e. P 50) using buttons
+ and - on the programmer.
Press button P on the programmer to confirm the
programmed values: the corresponding indicator
will turn On.
Press button P1 on the control panel to put all the
previously programmed data into memory P1: all
the indicators on the programmer will turn Off
(the only exception being the speed 3 indicator).
Turn the machine Off before removing the
programmer.
USE OF THE PROGRAMMER
26
