“Ice Twister”
After removing it from its place,
fill the “Ice Twister” with clean
water, being careful not to
overfill the ice forms. Place it
above the ice tray. After a few
hours the water freezes. Turn
the handle clockwise until the
cubes come loose and fall into the ice tray.
Can dispenser drawer
This part was specially
developed for storing cans of
350 ml of your favorite drink.
Eggs basket
The eggs basket is removable
and has a handle for better
movement between the
refrigerator, sink and table. Its
maximum capacity is 12 eggs.
Retractable and folding shelf
This shelf can be retracted and folded up, allowing
the storage of larger objects in the refrigerator
compartment, such as jars and cakes. To unlock
it, just lift and push the arrows indicated in front of
the frame. After sliding back, until the front shelf fit
into the rear shelf (position 1), you can tilt it back
(position 2). To remove it, lift the shelf until it stays
between positions 1 and 2, being about 45º from
horizontal and pull the shelf.
Fruits / Vegetables drawer
Keeps the moisture and
freshness of vegetables
and fruits due to cold air
circulation which is not in
direct contact with food.
For better preservation,
keep vegetables and fruits
at this place. This drawer
is removable and has side
handles.
Multi-Flow System
This system distributes the
cold air for cooling food in the
freezer and the refrigerator
compartments.
Warning: Always leave the air
openings free to facilitate the
circulation of cold air and thus
improve food preservation.
Removable multi-use shelf
This shelf is used to store
different kinds of food. It may
slide laterally or may be placed in
any of four bars. To remove the
shelf, remove the food from it and lift it up to release
the “click” of the door rail.
Freezer drawers
The two freezer drawers are
removable and has side
handles for easy handling.
A
Position 2
Position 1
36
Main components
