Feature Overview
CONTROL PAD FUNCTIONS - MODEL A
Bake Pad- Used to enter the normal baking mode temperature.
Broil Pad- Used to select the variable broil mode.
Convection Bake Pad- Used to select the convection baking mode.
Convection Roast Pad- Used to select the convection roasting mode.
Convection Broil Pad- Used to select the convection broil mode.
Warm Oven Pad- Used to select the warm oven mode.
Upper Oven Pad- Used to activate the upper oven for cooking operation.
Slow Cook Pad- Used to select the slow cook mode.
Multi Stage Pad- Used to enter up to three subsequent modes.
Defrost Pad- Used to select the defrost mode.
Dehydrate Pad- Used to select the dehydrate mode.
Bread Proof Pad- Used to select the bread proof mode.
Clean Pad- Used to select the self-cleaning mode.
Lower Oven Pad- Used to activate the lower oven for cooking operation.
Light Pad- Used to turn the oven light on and off.
Control Lock Pad- Used to disable all oven function.
Lite Pad- Used to start a 2 hours self-clean cycle.
Med Pad- Used to start a 3 hours self-clean cycle.
Heavy Pad- Used to start a 4 hours self-clean cycle.
User Preference Pad- Used to bring the user preference menu in the display.
2
3
1
4
6
7
8
9
10
11
12
13
14
15
16
17
5
18
19
20
7
8 9 10
1 2 3 4 5
11 12 13
14
15 16 17 18
6
19 20
