Electrolux ECWS3011AS - Product Dimensions

2
ELECTRIC WALL OVEN INSTALLATION INSTRUCTIONS
(with cooktop combination installations)
Figure 2
30" Double Wall Ovens
Do not remove spacers (if equipped) on the side walls of the built-in oven. These spacers
center the oven in the space provided. The oven must be centered to prevent excess heat buildup that may
result in heat damage or re.
NOTES:
1. Allow at least 21" (53.3 cm) clearance in front of
oven for door depth when it is open.
2. Dimension G (cutout depth) is critical to the
proper installation of the built-in oven. If the oven
trim does not butt against the cabinet, or if noise
is heard on convection models, verify dimension
G to assure it is according to the required
dimension.
3. For a cutout height greater than 49
3
/
4
" (126.4cm),
add one 2"(5 cm) wide wood shim of appropriate
height to each side of the opening under the
appliance side rails (not included).
All dimensions are in inches (cm).
B
B
A
A
D
D
F
F
I
I
H
H
G
G
C
C
48 5/8”
(124.1 cm)
11½”
(29.2 cm)
2”
(5.1 cm)
Min.
3” (7.6 cm
)
Max.
1½” (3.8 cm)
Min.
Door Open
(see note 2)
Hole for
Cable
Electrical
Junction Box
2" (5 cm) Wide Wood
Spacer if Needed
Spacer
PRODUCT DIMENSIONS
A B C D
30 (76.2 cm) 50
13
/
16
(129.0 cm) 28
1
/
4
(71.8 cm) 25
3
/
16
(63.9 cm)
CUTOUT DIMENSIONS AND CABINET WIDTH
F G (Min.)
H. Standard Height
(**Others, see notes 3)
I
Min. Max. Min. Max.
28
1
/
2
(72.4 cm) 29 (73.7 cm) 24 (61.0 cm) 48
7
/
8
(124.5 cm) 50
1
/
4
(127.6 cm) 30
1
/
8
(76.5 cm) Min
DOUBLE WALL OVEN INSTALLATION
