Description of machine
Control panel
What is shown in the display
Drawer containing
condensate tank
Screwed feet
(with height
adjustment)
Loading door
(interchangeable stop)
Operating screen
Large mesh filter
(lint filter)
Air slots
Lamp for inside light
Type plate
Base door upstream
of heat exchanger
M
icro-fine filter
(
lint filter)
Fine strainer
(lint filter)
Programme knob and
On/Off switch
Display
Function buttons START/PAUSE button
Current time
End of cycle
Options
Information field, shows the current settings
Door indicator
Spin speed Times
EXTRA DRY
Cycle end at
f 1200 ýýýýýmýWýgýSýBýaýaýTýk
15.01
12.45
