Electrolux EDW 1503 - Service Function: Fault Memory Readout (EDW 1100)

- 25 -
.
General information
- Calling the service functions is executed in all designs resp. key arrangements analogously.
- For that you always have to use the keys S0, S1, S2 andS3 independent of their variant-depending
program load.
- In the service function mode, key S1 is ALWAYS responsible for the function readout of fault memory
and single actuator selection.
It is generally valid:
For calling all service functions you always have first to actuate function keys S1 and S3 before switching
on the appliance by ON/OFF switch S0!
The keys have to remain pressed about 4 seconds to activate the function.
This procedure is intentionally different to that for the customer functions.
Calling the functions readout of fault memory and
single actuator selection
1. Press keys S1 and S3 simultaneously an...
2. ... and switch on the appliance by ON/OFF switch S0. For
that keep keys S1 and S3 pressed until the 3 confirmation
LEDs LD1, LD2 and LD3 are flashing.
(A temporary flashing up of
LEDs is possible and is no fault!)
3./4. By actuating the function key S1 you can call the
function. The confirmation LED LD1 continues flashing, LEDs
LD2 and LD3 go out.
When you press S1 button for the first time, the first error is
displayed in coded form by means of the END LED.
When S1 button is pressed the second and third time, you
can read the second and third value of the error memory.
(see description Overview of errors displayed
As from the fourth time you press the S1 button, LED LD1 will
go dark and LD2 starts flashing.
You can call the individual actuators one after the other now.
4. Actuation: selection of regeneration valve
5. Actuation: selection of drain pump
6. Actuation: selection of valve
(filling to level - if already existing, no filling)
7. Actuation: selection of heating
(only when level detected)
8. Actuation: selection of circulation pump
9. Actuation: selection of detergent dispenser
10. Actuation: selection of drying fan
All positions can be called scrolling as many times as one
wants.
The several steps are switched onward manually by pressing
any key. If the function key S1 is not pressed within 60
seconds, the service function is left automatically. Alle LEDs
der Programm- und Optionstasten leuchten. Das Gerät
befindet sich wieder im Vorstart-Modus.
It is also possible to leave the function by switching off the
appliance by ON/OFF key S0.
8.1.1 Service Function / Readout of fault memory and sin-
gle actuator selection:
1.
3.
S0
LD0
bli nkt
... AUS nach 60sek. automatisch
... AUS durch manuelle Betätigung über E i n/Aus
S0
LD0
S0
LD0
S0
LD0
LD1
S1
Tasten S1/S3 für ca. 4 Sek. halten bis LD1-LD3 blinken!
pr o T as tendr uck
1 Weiterschaltung
Anzeige 2. + 3.Fehlers
Codier te Anzeigen
der E inzelaktoren
S2
LD2
LD1
LD3
S1
2.
S0
LD0
LD2
LD1
LD3
blink en
S2
S1
LD2
bl ink t
LD1
S1
LD2
bli nkt
LD1
S1
LD2
4.
S0
LD0
bli nkt
LD1
S1
LD2
S1
