Electrolux EEA12100L - Product Description

spare parts are relevant for all
models.
• The following spare parts will be
available for 10 years after the model
has been discontinued: door hinge
and seals, other seals, spray arms,
drain filters, interior racks and plastic
peripherals such as baskets and lids.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
The graphics below is just a
general product overview.
For more detailed
information, refer to other
chapters and/or documents
provided with the appliance.
4
3
7
8
10 9
56
11
1
2
1
Upper spray arms
2
Lower spray arm
3
Filters
4
Rating plate
5
Salt container
6
Air vent
7
Rinse aid dispenser
8
Detergent dispenser
9
Cutlery basket
10
Lower basket
11
Upper basket
www.electrolux.com6
