4
PRODUCT DESCRIPTION
1
Ceiling mount bracket
2
Telescopic flue cover set
3
4
Wall bracket
5
Main body and fan housing assembly
Grease filters
additional items required for installation
t ixiF ngs required to attach rangehood body and anti tilt
points.
t ixiF ngs required to attach ceiling mounting bracket and
hood bracket to the wall.
t ac ro epat tcuD ble ties.
Technical Specification
Power supply: 220-240 Volts 50Hz. Connects to
7.5A power point.
Lights: LED 1 x 8.5 watt, 12 Volt LED
1
2
3
4
5
Fig. 3
