5.
6.
7.
8.
A) supplied seal
B) supplied brackets
9.
10.
CAUTION!
Install the appliance only on
a worktop with flat surface.
3.8 Installation of more than
one hob
If several hobs are to be installed side by
side into the same cut out, an assembly
kit including a support side bracket and
supplementary seals is available at our
Authorised Service Centres. The relevant
installation instructions are supplied
within the kit package.
3.9 Installing hob under the
hood
If you install the hob under a
hood, please see the
installation instructions of the
hood for the minimum
distance between the
appliances.
3.10 Possibilities for insertion
The panel installed below the hob must
be easy to remove and let an easy
access in case a technical assistance
intervention is necessary.
Kitchen unit with door
www.electrolux.com10
