15
MODEL - ELECTROLUX EGG 7432S PARTS LIST
REF # :
H/A/332
NO CODE NO PART NAME UNIT (PCS)
1 TH-0002/EF GLASS - 3 BURNER ( NICKY ) 1
2 TH-0002/BC BOTTOM PLATE - 3 BURNER (Z) SABAF 1
3 TH-0004/BZ IRON PIPE (3 BURNER) WITH FITTING (L:40.5) 1
4 TH-0004/KH BRASS NUT HEX 14MM x M12 x 1.2 1
5 TH-0004/KD FITTING NUT HEX 25.4 x L45.5MM 1
6 TH-0004/VQ ALUMINIUM PIPE (LZO) 3BG 1
7 TH-0004/XQ ALUMINIUM PIPE (RZO) 3BG 1
8 TH-0005/AH IGNITION VALVE (S) BKP (J) III-100 3
9 TH-0005/RA IGNITION VALVE BRACKET (THH-006) 3
10 TH-0005/VA BATTERY BOX 1
11 TH-0005/XB GENERATOR 3P (SABAF) 1
12 TH-0005/UC GENERATOR COVER 1
13 TH-0005/UE BATTERY BOX COVER 1
14 TH-0006/ZB TRIPLE CROWN BODY WITH INJECTOR 2
15 TH-0006/ZA BURNER TRIPLE CROWN WOK CYCLIN 2
16 TH-0006/ZD B/CAP TRIPLE CROWN OUTER GLOSS 2
17 TH-0006/ZC B/CAP TRIPLE CROWN INNER GLOSS 2
18 H2-0219/AP SCREW -MSP 4*8 (SW) 6
19 TH-0004/KI FEMALE NUT - ZINC PLATING 3
20 TH-0004/LC OLIVE 7MM 3
21 TH-0005/ZZ SPARKER CLIP 3
22 TH-0026/AD SHRINK TUBE - 6X10MM 2
23 TH-0005/ZB SPARKER FOR TRIPLE FLAME 2
24 TH-0006/YX SABAF BURNER STAND - BIG -NICKY 2
25 TH-0008/KA K.STAND - GLASS HOB (R) BH 2
26 TH-0008/KB K.STAND - GLASS HOB (R) BL 1
27 GH-0025/AA CONNECTOR 1
28 TH-0009/DA ENAMEL TRAY BIG (L) 1
29 TH-0011/AE SILICONE RUBBER TUBING D- 165MM 3
30 TH-0016/BZ KNOB (NICKY) 3
31 TH-0018/AH SCREW M4x10 ( TAPLITE ) S/S 12
32 TH-0018/AP SCREW S/S 6
33 TH-0018/AL SCREW M4x6 ( TAPLITE ) S/S 4
34 TH-0015/AB GASKET FOR CONNECTOR 1
35 TH-0003/CA INJECTOR 0.98) 2
36 TH-0004/ZQ ALUMINIUM PIPE (CZO) 3BG 1
37 TH-0006/ZF SEMI RAPID B/BODY WITH INJECTOR 1
38 TH-0006/ZE BURNER CROWN SEMI RAPID 1
39 TH-0006/ZG BURNER CAP SEMI RAPID GLOSS 1
40 TH-0014/AB FOAM WITH ONE SIDE D/SIZE TAPE 2.7
