Assembly
600
680 +1
R5
490 +1
=
=
min. 5 min. 5
min. 20
min. 25
min. 5
min. 20
min. 38
min. 5
Warning! Surface temperature of base exceed 95°C,
under bench access must be restricted by
use of non-combustible barrier or installation.
electrolux 15
