Electrolux EIGD55H - Dryer Installation Dimensions

IInnssttaallllaattiioonn IInnffoorrmmaattiioonn
2-4
38.00”
(96.5cm)
16.25”
(41.5cm)
18.25”
(46.5cm)
53.00”
(134.5cm)
1.4”
(3.5cm)
3.75”
(9.5cm)
13.50”
(34.5cm)
To center of rear vent
3.40”
(8.5cm)
Gas supply
pipe on rear
of gas unit
50.6” (128.5cm)*
To clear open door
31.50” (80cm)*
To front of closed door
27.00”
(68.5cm)
Centerline
height for
rear vent
Electrical
supply on
rear of unit
Freestand dryer
on oor
* To obtain these minimal depth dimensions, dryer must either be vented straight back
or with a quick-turn90° elbow. Connection of water inlet hose on Steam Models
adds 3/4 in. (2 cm) to installation depth.
Floor line
Floor line
Dryer mounted on
optional pedestal
75.75”
(192.5cm)
41.00”
(104cm)
39.00”
(99cm)
Gas supply
pipe on rear
of gas unit
50.6” (128.5cm)*
To clear open door
31.50” (80cm)*
To front of closed door
Centerline
height for
rear vent
Electrical
supply on
rear of unit
* To obtain these minimal depth dimensions, dryer must either be vented straight back or with a quick-turn 90° elbow.
Connection of water inlet hose on Steam Models adds 3/4 in. (2 cm) to installation depth.
27.00”
(68.5cm)
DDrryyeerr IInnssttaallllaattiioonn DDiimmeennssiioonnss
FFiigguurree 22--11..
