Electrolux EL5020A - Parts Removal; Installation Guide; Tools Required

2
Table Of Contents
Parts Removal / Installation Guide
Belt and Brushroll Section A Page 3
Rear Wheel Assembly Section B Page 3
Hood Assembly Section C Page 3
Main Control Board Section D Page 4
Handle Assembly Section E Page 4
Brushroll Motor Assembly Section F Page 4
Suction Motor Assembly Section G Page 5
Cord Reel Assembly Section H Page 5
Tools Required:
Safety glasses
Clean Pad or soft cloth (to prevent scratching of plastic parts during repair)
Needle nose pliers
Phillips Screw Driver
Flat Head Screw Driver
Torx-20 screwdriver
Wire cutter pliers
Wire nut crimpers
3/8 Nut Driver
Note: Before any repair work is performed make sure that the unit is
unplugged
