oven door removal electrolux e:line ovens 2726 electrolux e:line ovens oven door removal
Cleaning door glass panels
warning
Do not to use harsh abrasives on the glass panes as the
reectivesurfaceplaysaroleinthefunctionoftheoven.
Do not place glass in dishwasher. Hand wash only with a
softclothandwarmsoapywater.Whendrypolishwitha
soft cloth and ensure the glass is dry before reassembly.
Bottomtrim(onselectedmodels)
• Thebottomtrimmayberemovedforcleaningby
snapping out and lifting away from the glass.
Re-assemblingbottomtrim
• Pushdownto“snap”eachsideofbottomtrimbackinto
door columns.
Re-assemblingdoorglasspanels
• Insertthesmallerclearglasspanel(whentted)rst
from above and at an angle to the profile of the door.
• Repeatfortheblackborderedglasspanelensuringthe
painted surface is facing to the downside.
Re-assemblingtopdoortrim
• Takeholdofthetopdoortrimateachsideandposition
it to the inside edge of the glass.
• Pushthetrimdownwithitstopedgeoverglasspanel
until the clip snaps in on each side of the trim.
• Pushthemiddleofthetrimdowntoensureitisstraight
and firm against the glass panel.
Fittingtheovendoor
• Takeholdoftheovendoorwithahandoneachside
andwiththedooratanangleof45º,positionthe
recesses at the bottom of the door onto the hinge arms
of the oven. Let the door slide down the hinge arms as
far as it will go.
• Openthedoorfullytoaccessthehingesthenrotate
the‘stirrups’(highlightedintheimage)onbothhinges
back to their original positions. The oven door may now
be closed.
