Electrolux EOG 21300 - Electrical Connection

electrolux 33
Electrical connection
The instructions given belowThe instructions given below
The instructions given belowThe instructions given below
The instructions given below
are designed specifically for aare designed specifically for a
are designed specifically for aare designed specifically for a
are designed specifically for a
qualified installer and shouldqualified installer and should
qualified installer and shouldqualified installer and should
qualified installer and should
aid him or her to perform allaid him or her to perform all
aid him or her to perform allaid him or her to perform all
aid him or her to perform all
installation, adjustment, andinstallation, adjustment, and
installation, adjustment, andinstallation, adjustment, and
installation, adjustment, and
maintenance operations withmaintenance operations with
maintenance operations withmaintenance operations with
maintenance operations with
absolute precision and inabsolute precision and in
absolute precision and inabsolute precision and in
absolute precision and in
compliance with all currentcompliance with all current
compliance with all currentcompliance with all current
compliance with all current
legislation and regulations. Welegislation and regulations. We
legislation and regulations. Welegislation and regulations. We
legislation and regulations. We
strongly recommend that allstrongly recommend that all
strongly recommend that allstrongly recommend that all
strongly recommend that all
operations for the installationoperations for the installation
operations for the installationoperations for the installation
operations for the installation
of your of your
of your of your
of your
ovenoven
ovenoven
oven
be carryed out be carryed out
be carryed out be carryed out
be carryed out
by Qualified Personnel inby Qualified Personnel in
by Qualified Personnel inby Qualified Personnel in
by Qualified Personnel in
accordance with existing rulesaccordance with existing rules
accordance with existing rulesaccordance with existing rules
accordance with existing rules
and regulations.and regulations.
and regulations.and regulations.
and regulations.
Electrical connection
Prior to making the electrical connection,
make sure that:
— the protection fuse and the domestic
wiring system are suitable to carry the
total electric load of the oven (see rating
plate);
— your domestic wiring system has an
efficient earth connection in compliance
with rules and laws in force;
— the wall socket or the omnipole switch
used for the electrical connection can
easily be reached after the oven is built
in.
This appliance is delivered without an
electric supply cable, therefore, you will
have to fit to it a supply cable with standard
plug, suitable for the total electric load
shown on the rating plate. The plug is to
be inserted into a suitable wall socket. If
you require a direct connection to the
electric network (mains), it will be necessary
to fit between the appliance and the mains
an omnipole switch, with a minimum gap
between contacts of 3 mm, suitable for
the required load and in compliance with
rules in force. The green & yellow ground
wire must not be interrupted by the switch
and it should be 2-3 cm. longer than the
other cables. The supply cable must in all
cases be laid out in such a way as to ensure
that it does not reach at any given point a
temperature 50°C higher than the ambient
temperature.
Suitable power supply cables are the
following types, considering the respective
necessary section of cable: H07 RN-F,
H05 RN-F, H05 RR-F, H05 VV-F, H05 V2V2-
F (T90), H05 BB-F.
The replacement of electric cable
must be carried out exclusively by
the service force centre or by
personnel with similar
competencies, in accordance with
the current regulations.
Terminal block
The oven has an easily accessible terminal
block, which is meant to work with an
electric single-phase rate of 230 V.
The Manufacturer disclaims anyThe Manufacturer disclaims any
The Manufacturer disclaims anyThe Manufacturer disclaims any
The Manufacturer disclaims any
liability in case theseliability in case these
liability in case theseliability in case these
liability in case these
accident-preventing rules are notaccident-preventing rules are not
accident-preventing rules are notaccident-preventing rules are not
accident-preventing rules are not
observed.observed.
observed.observed.
observed.
