3. PRODUCT DESCRIPTION
1 2
6
3
4
5
7
8
9
10
1
Water container
2
Control panel
3
Internal light
4
Appliance door
5
Filter
6
Rating plate
7
Airflow slots
8
Heat Exchanger lid
9
Heat Exchanger cover
10
Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
4. CONTROL PANEL
1
1112 10 9 8
5
7
6
432
1
Programme knob and RESET
switch
2
Ochrona przed zagnieceniami touch
button
3
Poziom wysuszenia touch button
4
Display
5
Suszenie na czas touch button
6
Start/Pauza touch button
7
Opóźniony start touch button
8
Odświeżanie touch button
9
Sygnał końca cyklu touch button
10
Obroty Plus touch button
11
Tryb cichy touch button
12
On/Off button
ENGLISH 7
