Electrolux EWF12832 - Product Description

ENGLISH 5
PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Door Blocking button
14
Rating Plate
15
Drain Pump Filter
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support
12
Level Adjustment Feet (Back)
Transit Bolts
To remove the transit bolts.
To adjust levelling legs.
To connect the drain hose on the edge
of a sink.
Plastic caps
To close the holes on the rear side of
the cabinet after the removal of the
transit bolts.
ACCESSORIES
Plastic hose guide
Spanner
-
-
14
13
1
4
5
6
12
7
8
9
10
11
2
3
15
