5 ENGLISH
Air inlet
Air Outlet
Air inlet (side)
Air inlet (rear)
Air outlet
1 Front panel
2 Pre-dust 󰘰lter
3 Air 󰘰lter
4 Digital display
5 Cold plasma generator (inside)
6 Manual control button
7 Refrigerant pipe
8 Drain hose
9 Connecting cable
10 Remote controller
11 Vertical air flow louver
12 Horizontal air flow grille
All the pictures in this manual are for explanation
purposes only. The actual shape of the indoor
unit you purchased may be slight di󰘯erent on front
panel and display window. The actual shape shall
prevail.
