PRODUCT DESCRIPTION
UNIT DESCRIPTION
4
3
2
1 5
6
1
2
3
4
5
6
1
CONTROL PANEL
2
CARRYING HANDLE (BOTH SIDES)
3
REMOTE CONTROL STORAGE DOOR
4
REMOTE CONTROL
5
ROOM AIR DISCHARGE
6
CASTOR
1
EXHAUST AIR OUTLET
2
EXHAUST ADAPTOR A
3
BOTTOM TRAY DRAIN OUTLET
4
AIR INTAKE
5
DEHUMIDIFYING DRAIN OUTLET
6
EXHAUST HOSE (STORAGE WHEN
NOT IN USE)
ACCESSORIES
Check all the accessories are included
in the package and please refer to the
“Installation” chapter for their usage.
ABCD
EF G
H
IJ
PART PART NAME QUANTITY
A Exhaust hose 1 pc
B
Unit/Exhaust Adaptor A 1 pc
4 electrolux
