Electrolux EXP35U538CW User Manual

14
www.electrolux.com
7.
OPERATING INSTRUCTIONS
Some of the following instructions
can only be used by using the
Control Panel.
It is not necessary to use the
drainage hose in the “cool” mode.
Cooling mode
Heating mode (on some models)
In this mode the exhaust adaptor hose
MUST be used.
In this mode the exhaust adaptor hose
MUST be used.
7.1
Usage of the Control Panel
1.
Press the “mode” button until the Cool
mode indicator is lit.
2.
Press the “fan speed” button to
choose the fan speed according
to the illumination of the fan speed
indicator. You can choose the
fan speed as following sequence:
“auto” → “hi” → “med” → “low” → “auto”.
3.
Press the “
” or “ ” button to choose
the temperature you want.
1.
Press the “mode” button until the “Heat”
indicator is lit.
2.
Press the “fan speed” button to
choose the fan speed according
to the illumination of the fan speed
indicator. You can choose the
fan speed as following sequence:
“auto” → “hi” → “med” → “low” → “auto”.
3.
Press the “
” or “ ” button to choose
the temperature you want.
4.
Connected drain hose. See 7.4
Drainage section.
6.
AIR CONDITIONER FEATURES
6.1
CONTROL PANEL

  
1
2
7
3
4
5
6
8
9
Displays temperature/time
Power ON/OFF
Sleep
Filter Reset
Fan Speed
Adjust Temperature or Timer
Mode Selection
Timer
Swing
Dry mode
Press the “mode” button until the Dry
mode indicator is lit. The screen displays
the room temperature.
At the same time, the “low” fan indicator
lights.
Note:
In this mode, fan speed cannot
be selected.

Electrolux EXP35U538CW Specifications

General

Type	Monobloc mobile air conditioner
Timer	Yes
Noise level	64 dB
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.6 l/h
Timer duration (maximum)	24 h
Air conditioner functions	Cooling
Heating capacity in watts (max)	- W
Heating energy efficiency (COP, W/W)	-
AC input voltage	220 V
Energy efficiency class (cooling)	A+
Hourly energy consumption (cooling)	3.5 kWh
Product color	White

Weight and Dimensions

Width	- mm
Weight	34000 g
