Electrolux IC43316 - Method of Use; Control Console

0409
1
3
1
2
4
5
6
7
8
9
10
3
HONEYWELL DC1010
PV
SP
AL2
OUT2
AL1
PRO
OUT1
AT
SET
D1323
3
2
18
45
6
7
01103040
PageNotice Date
OPERATING
HANDBOOK
3. Method of use
Control consol
1. "Voltage" indicator
2. "Stop" switch
3. "On" switch
4. "Ironing speed adjustment" potentiometer
5. "Ironing temperature selection" thermostat
6. "Heating" indicator on
7. Gas heating "Ignitor failure" indicator
8. "On / Off" heating switch with "On" indicator
