Electrolux KODEH70X User Manual

4. PRODUCT DESCRIPTION
4.1 General overview
9
8
13
12
5
4
1
2
3
4 7631 52
10
11
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Plus Steam
8
Heating element
9
Lamp
10
Fan
11
Cavity embossment - Aqua cleaning
container
12
Shelf support, removable
13
Shelf positions
4.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Baking tray
For cakes and biscuits.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.
• Telescopic runners
With the telescopic runners you can put in
and remove the shelves more easily.
5. CONTROL PANEL
5.1 Retractable knobs
To use the appliance press the knob. The
knob comes out.
5.2 Sensor fields / Buttons
To set the time.
To set a clock function.
To set the time.
To turn the True Fan Cooking PLUS function on and off.
8 ENGLISH

Electrolux KODEH70X Specifications

General

Connected load	2990 W
AC input voltage	220-240 V
AC input frequency	50-60 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	95.3
Energy consumption (conventional)	0.93 kWh
Energy consumption (forced convection)	0.81 kWh
Oven size	Medium
Oven type	Electric
Top heating	-
Cleaning type	Steam
Bottom heating	Yes
Number of ovens	1
Microwave cooking	No
Cleaning technology	AquaClean
Oven thermostat range	50 - 275 °C
Number of cooking programs	9
Total oven(s) interior capacity	72 L
Door hinge	down
Cord length	1.6 m
Noise level	43 dB
Control type	Rotary, Touch
Display type	LED
Product color	Stainless steel
Control position	Front
Appliance placement	Built-in
Timer type	Digital
Timer modes	Cooking time, End cooking time, Timer
Lamp type	Halogen

Weight and Dimensions

Depth	569 mm
Width	596 mm
Height	594 mm
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	600 mm
