3.2 Securing the oven to the cabinet
4. PRODUCT DESCRIPTION
4.1 General overview
10
8
9
17
14
15
13
5
4
1
2
3
4 63 5 721
11
12
16
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Water tank indicator
8
Water drawer
9
Heating element
10
Lamp
11
Fan
12
Cavity embossment - Aqua cleaning
container
13
Shelf support, removable
14
Draining pipe
15
Water outlet valve
16
Shelf positions
17
Steam inlet
4.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Baking tray
For cakes and biscuits.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.
8 ENGLISH
