FUNCTION OF IMPORTANT COMPONENTS
4. Operation of damper is shown below.
Cooking Mode Operation of Damper
Microwave cooking Open
Convection cooking Closed
Grill; during backed up with
Convection heating element
Closed
Grill; afther convection heting
element backed up has stopped
Open
Dual (Microwave and Convection) Closed
Dual (Microwave and Grill) Open
Fire sensing condition Closed
TROBLESHOOTING GUIDE
When troubleshooting the microwave oven, it is helpful
to follow the Sequence of Operation in performing the
checks. Many of the possible causes of trouble will
require that a specific test be performed. These tests
are given a procedure letter which will be found in the
“Test Procedure” section.
IMPORTANT: If the oven becomes inoperative
Because of a blown fuse F2 (F8A) in
the monitored latch switch SW1 –
monitor switch SW3 circuit, check the
monitored latch switch SW1 and
monitor switch SW3 before replacing
the fuse F2 (F8A).
