Electrolux NUC1 User Manual

5
ENGLISH
A4 TECHNICAL DATA
Standard cycle time may vary should the inlet water temperature be different from that indicated above.
(**) With dynamic feed pressure of 200 kPa [2 bar].
(&) FUCA3DD
MODEL ZUCA1 ZUCA3 /
FUCA3DD
NUCA1DDG NUC1GMS NUC1 -
EUC1
NUC1G -
EUC1G
NUC3 -
KUC3 -
EUC3
Supply voltage: V 220-240V 1N 400-415V 3N 220-240V 1N 220-240V 1N 220-240V 1N 220-240V 1N 400-415V 3N
- convertible to V - 220-240V 3 400-415V 3N - - 400-415V 3N 220-240V 3
- convertible to V - 220-240V 1N 220-240V 3 - - 220-240V 3 220-240V 1N
Frequency Hz 50 or 60 50 or 60 50 or 60 50 or 60 50 or 60 50 or 60 50 or 60
Max. power input kW 3,65/5,65(*) 5,35/7,35(*) 5,35 3,65/5,65(*) 3,65/5,65(*) 2,85/4,35(*) 5,35/7,35(*)
Boiler heating
elements
kW 2,8 4,5 4,5 2,8 2,8 1,5 4,5
Tank heating
elements
kW 2,0 2,0 2,0 2,0 2,0 2,0 2,0
Water supply
press.
kPa
[bar]
50-700 [0,5-7] 50-700 [0,5-7] 50-700 [0,5-7] 200-300 [2-3] 200-300 [2-3] 200-300 [2-3] 200-300 [2-3]
Water supply
temp.
°C 50 50 50 65 50 50 50
Water supply
hardness
°f/°d/°e 14/8/10 max 14/8/10 max 14/8/10 max 14/8/10 max 14/8/10 max 14/8/10 max 14/8/10 max
Rinse cycle water
consumption
l 3 3 3 3 (**) 3,3 (**) 3,3 (**) 3,3 (**)
Boiler capacity l 5,8 5,8 5,8 5,8 5,8 5,8 5,8
Tank capacity l 33 33 33 33 33 33 33
Standard cycle
time with water
supply at 50°C
sec. 90 - 120 - 240 90 - 120 -
240 / 120 -
180 (&)
90 - 180 - 120 - 180 120 - 180 120 - 180
Standard cycle
time with water
supply at 65°C
sec. - - - 90 - 180 - - -
Legal noise level
Leq
dB(A) <70 <70 <70 <70 <70 <70 <70
Protection rating IPX4 IPX4 IPX4 IPX4 IPX4 IPX4 IPX4
Net weight Kg 54 54 54 54 54 54 54
Power supply
cable
H07RN-F H07RN-F H07RN-F H07RN-F H07RN-F H07RN-F H07RN-F
(*) = If activated by software, coincidence of tank and boiler heating elements.
Table 1
400-415 V 3N 220-240V 3 220-240V 1N
C SCSCS
2,85 kW
5X1,5 mm
2
16 A 3P+N
4X1,5 mm
2
16 A 3P+N
3X2,5 mm
2
16 A 1P+N
3,65 kW - - - -
3x2,5 mm
2
20A 1P+N
4,35 kW
5X2,5 mm
2
20 A 3P+N
4X2,5 mm
2
20 A 3P+N
3X2,5 mm
2
25 A 1P+N
5,35 kW
5X1,5 mm
2
16A 3P+N
4X1,5 mm
2
16A 3P+N
3x4 mm
2
32A 1P+N
5,65 kW - - - -
3X4 mm
2
32 A 1P+N
7,35 kW
5X2,5 mm
2
25 A 3P+N
4X4 mm
2
32 A 3P+N
3X6 mm
2
40 A 1P+N
C = Power supply cable
S = On/Off switch
Table 2
