14 www.electrolux.com
4. Stand the refrigerator, open the upper
door and remove the door shelves and
close it.
5. Unscrew the screw with a cross-
shaped screwdriver,then use a putty
knife or thin-blade screwdriver to
prie the screw hole cover which is at
the top left corner of the refrigerator,
and Unscrew the upper hinge cover
which is at the top right corner of the
refrigerator.
6. Unscrew the special ange self-tapping
screws which are used for xing the
right upper hinge part by a 8mm
socket driver or a spanner (please
support the upper door with your hand
when doing it).
7. Remove the upper hinge axis, transfer it
to reversed side and tighten securely.
8. Lift the upper door and set it on a non
scratching surface with the outside up.
NOTE: When removing the door, watch for
washer(s) between the center hinge and
the bottom of the freezer door that may
stick to the door. Do not lose these.
9. Unscrew the two special ange
self-tapping screws which are used
for xing the middle hinge part, then
remove the middle hinge part that hold
the lower door in place.
10. Lift the lower door and set it on a non
scratching surface with the outside up.
NOTE: When removing the door, watch for
washer(s) between the ceter hinge and the
bottom of the freezer door that may stick
to the door. Do not lose these.
11. Remove the screw hole cover from
the left holes as illustrated and transfer
them to the uncover holes at the right
side.
