C.3 New concept appliance
This appliance is a product specifically designed to heat/cook
sandwiches, with the following main characteristics:
• Combination of three different heating modes:
– contact plates,
– infrared radiation,
– microwaves.
• Different preset programs.
• Count down at the end of the cooking cycle.
• Programmable electronic control.
C.4 Machine and manufacturer's
identification data
A reproduction of the marking or data plate on the machine is
given below:
The data plate gives the product identification and technical
data.
The meaning of the various information given on it is listed
below:
F.Mod. factory description of product
Comm.
Model
commercial description
PNC production number code
Ser.No. serial number
“V“ power supply voltage
“Hz“ power supply frequency
“kW“ max. power absorbed
“A“ max. current absorbed
“IP or IPX“ dust and water protection rating
CE CE marking
Electrolux
Professional
SpA
manufacturer
Fig. 1 Data plate position
IMPORTANT
Refer to the data given on the machine's data plate
for relations with the Manufacturer (e. g. when
ordering spare parts, etc.).
C.5 Copyright
This manual is intended solely for consultation by the operator
and can only be given to third parties with the permission of
Electrolux Professional company.
C.6 Responsibility
The Manufacturer declines any liability for damage and
malfunctioning caused by:
• non-compliance with the instructions contained in this
manual;
• repairs not carried out in a workmanlike fashion, and
replacements with parts different from those specified in
the spare parts catalogue (the fitting and use of non-original
spare parts and accessories can negatively affect machine
operation and invalidates the original manufacturer
warranty);
• operations carried out by non-specialised personnel;
• unauthorized modifications or operations;
• missing, lack or inadequate maintenance;
• improper machine use;
• unforeseeable extraordinary events;
• use of the machine by uninformed and / or untrained
personnel;
• non-application of the current provisions in the country of
use, concerning safety, hygiene and health in the workplace.
The Manufacturer declines any liability for damage caused by
arbitrary modifications and conversions carried out by the user
or the Customer.
The employer, workplace manager or service technician are
responsible for identifying and choosing adequate and suitable
personal protection equipment to be worn by operators, in
compliance with regulations in force in the country of use.
The Manufacturer declines any liability for inaccuracies con-
tained in the manual, if due to printing or translation errors.
Any supplements to the installation, use and maintenance
manual the Customer receives from the Manufacturer will form
an integral part of the manual and therefore must be kept
together with it.
C.7 Keeping the manual
The manual must be carefully kept for the entire life of the
machine, until scrapping. The manual must stay with the
machine in case of transfer, sale, hire, granting of use or
leasing.
C.8 Recipients of the manual
This manual is intended for:
• the carrier and handling personnel;
• installation and commissioning personnel;
• the employer of machine users and the workplace
manager;
• operators for normal machine use;
• specialised personnel - Customer Care service (see service
manual).
