Electrolux VP-1 - Wiring Diagram

The Greens Machine
VP-1 and VP-3
Salad & Vegetable Dryer
Item Old # New # Description Req.
1 30011 653628 VP-1 Outer Lid Stainless 1
30006 653627 VP-3 Outer Lid-Poly (Green) 1
2 30-0018 0US127 Bushing 1
3 30-0016 0US233 “T” Handle 1
4 30010 653626 Inner Bucket & Lid 1
5 30-0014 0US005 Octagonal Drive Casting 1
6 N/A N/A Main Body 1
7 1022 0US196 Electrical Cord 1
8 30-0052 0US136 VP-1 Base - Green 1
30-0042 0US134 VP-3 Base - Gray 1
9 31-007 0US166 Timer Knob 1
10 30-0004 0US171 Timer 1
11 1157 0US031 6-32 x 1/2'' Screw 2
12 1520 0US251 Strain Relief 1
13 30-0047 0US104 1/2'' x 8 Sheet Metal Screw 6
14 30-0046 0US135 Cover Plate 1
15 30-0013 0US247 Capacitor on Motor 1
30-0006 0US016 Capacitor (old style) 1
16 30-0015 0US014 Mounting Strap (old style) 1
17 30004 0US250 Motor - w/capacitor 1
18 22-0028 0US331 Grommet 1
19 30-0034 0US118 Caster - Flat 1
20 30-0039 0US071 1/4'' Flat Washer (Large) 4
21 30-0038 0US074 1/4'' Lock Washer 20
22 30-0037 0US070 1/4''-20 x 3/4'' Bolt 12
23 30-5001 0US068 1/4''-20 x 1'' Bolt 4
24 30-5003 0US073 1/4'' Flat Washer (Small) 16
Not Shown
30-0036 0US243 VP-1 Lid Hook
WIRING DIAGRAM
Machine shall be connected to the branch circuit with
overcurrent protection of 15 Amps.
Motor w/separate capacitor.
Dimensions (subject to change)
Height: 32.5''
Diameter: 27''
Shipping Weight: VP-1 80 lbs.
VP-3 60 lbs.
Space Required: 26.5'' wide
Gravity Drain: 1.5'' wide
RPM: 406
Electrical 115V/60H/1P/2.7 amps
Diameter: 27''
Inner Liner
Capacity: 20 gal./18 lbs.
Diameter: 15.68''
Depth: 17''
