Electrolux W4400H - Page 9

9

 

 




5867
S
T
R
P
O
8
N
M
F
11
10
L
G
H
I
K
9
4
5
6
12
The movement
when tilting
9
B
A
E
C
1
2
3
D
Front
Right side
W4400H
A B C D E F G H I K L M N O P R S T U V
1325 1450 2015 910 300 1865 270 820 420 435 425 525 660 2235 950 830 370 2205 1140 345
9 (only W3600H,
W4400H)
Rear side
G
7
(only W3600H,
W4400H)
7 (only W3850H, W31100H)
U
V
W3600H
A B C D E F G H I K L M N O P R S T U V
1390 1600 2015 970 200 1850 270 660 525 425 860 1565 420 430 2200 1120 2180 955 275 275
Technical data
Dimensions
1 Control panel
2 Door opening ø 700
3 Soap supply injector, powder
(optional)
4 Cold water connection
5 Hot water connection
6 Third water connection (optional)
7 Steam connection
8 Drain
9 Electrical connection
10 Compressed air
11 External liquid supply,
6 pcs ø 10, 1 pc ø 16 and 1 pc ø 20
12 Water connection, soap supply injector (optional)
