5. Take out the laundry and then close
the appliance door.
6. Close the filter flap.
14. TECHNICAL DATA
Dimension Width/ Height/ Depth/
Total depth
600 mm/ 850 mm/ 605 mm/ 639
mm
Electrical connection Voltage
Overall power
Fuse
Frequency
230-240 V
2200 W
13 A
50 Hz
Level of protection against ingress of solid parti-
cles and moisture ensured by the protective cov-
er, except where the low voltage equipment has
no protection against moisture
IPX4
Water supply pressure
1)
Minimum
Maximum
0,5 bar (0,05 MPa)
8 bar (0,8 MPa)
Emission sound pressure level in accordance with
EN ISO 11204/11203
< 70 dB
Water supply
2)
Cold water
Hot water
3)
Maximum Load Cotton 8 kg
Energy Efficiency Class A+++
Spin Speed Maximum 1400 rpm
1)
The appliance works correctly if the water pressure is not less than 0.05 MPa (0.5 bar). If
you can not connect the water inlet hose to the cold water tap of the primary hydraulic system,
connect it to your domestic cold water storage system. Make sure not to have more than a
distance of 5.02 m (16.5 ft) between the appliance inlet hose and the bottom of the water stor-
age tank.
2)
Connect the water inlet hose to a water tap with a 3/4'' thread.
3)
Make sure that the hot water temperature of your domestic system is not more than 55 °C.
15. ENVIRONMENT CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable containers
to recycle it. Help protect the environment
and human health and to recycle waste of
electrical and electronic appliances. Do
not dispose appliances marked with the
ENGLISH
29
