1
Spanner
To remove the transit bolts.
2
Plastic hose guide
To connect the drain hose on the edge of a
sink.
3
Plastic caps
To close the holes on the rear side of the
cabinet after the removal of the transit
bolts.
4
Inlet hoses
To connect the appliance to the cold and
hot water tap: blue cap hose for cold water
and red cap hose for hot water.
5
Flap for liquid detergent
To slow down the liquid detergent flow.
2.3 Installation on suspended
flooring
Suspended wooden floors are particularly
susceptible to vibration.
To help prevent vibration we recommend
you place a waterproof wood panel, at
least 15 mm thick under the appliance,
secured to at least 2 floor beams with
screws, the wood panel must extend
beyond the front feet.
If possible install the appliance in one of
the corners of the room, where the floor is
more stable.
2.4 Available from your
authorized vendor
Only appropriate accessories
approved by Electrolux
ensure the safety standards
of the appliance. If
unapproved parts are used,
any claims will be invalidated.
ENGLISH
7
