CAUTION!
Make sure that the drum is
not rotating. Wait till the
drum stops rotating, if
necessary.
Make sure that the water
level inside the drum is not
too high. Proceed with an
emergency drain, if
necessary (refer to
«Emergency drain» in
«Care and cleaning»
chapter).
To open the door, proceed as follows:
1. Press the button to switch the
appliance off.
2. Disconnect the mains plug from the
mains socket.
3. Open the filter flap.
4. Pull twice the emergency unlock
trigger downward and open the
appliance door.
5. Take out the laundry and then close
the appliance door.
6. Close the filter flap.
14. TECHNICAL DATA
Dimension Width/ Height/ Depth/
Total depth
600 mm/ 850 mm/ 605 mm/ 639
mm
Electrical connection Voltage
Overall power
Fuse
Frequency
220-230 V
2200 W
13 A
50 Hz
Level of protection against ingress of solid parti-
cles and moisture ensured by the protective cov-
er, except where the low voltage equipment has
no protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0,5 bar (0,05 MPa)
8 bar (0,8 MPa)
Emission sound pressure level in accordance with
EN ISO 11204/11203
< 70 dB
Water supply
1)
Cold water
Hot water
2)
Maximum Load Cotton 8 kg
Energy Efficiency Class A+++
Spin Speed Maximum 1400 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
2)
Make sure that the hot water temperature of your domestic system is not more than 55 °C.
www.electrolux.com26
