DGS-TDS-N 05.2006 © Electrolux 12 168 650
6.2 Replacing electrical elements
6.2.1 Replace operation
1. Remove the cover cap
2. Loosen the screws
3. Protect the buttons with adhesive tape
4. Loosen the printed circuit board screws
5. Carefully remove the printed circuit board from the
clamp
6. Carefully remove the printed circuit board connector
7. When installing the operation, ensure that the cable
protects the cable before the soldering tip and that the
sensor is not bent.
It is imperative that the chiller be disconnected from the mains prior to
work being carried out on the electrical system!
The electrical safety (accidental contact protection) is to be ensured by
the installation.
