DGS-TDS-N 05.2006 © Electrolux 16 168 650
6.3.3 Replace the capacitor
1. Warm up the capacitor connections with a soldering flame and loosen them
2. Loosen the screwed connections of the capacitor
3. Screw on a new capacitor
4. Reconnect the connections to the compressor and the
dry cartridge
Risk of Explosion (see 6.3.1)
6.3.4 Always replacing dry cartridges
1. Cut-off the dry cartridge connections directly above
the dry cartridge with a special cutting tool.
2. Remove the dry cartridge
3. Position the new dry cartridge
4. Solder the dry cartridge on
Risk of Explosion (see 6.3.1)
