Page 40
7. ACCESSING COMPONENTS THROUGH THE BASE
7.1 Tray Spillage Removal
a) Lay the appliance on its left hand side
b) Unclip tray spillage as indicated in the picture
7.2 Circulation Pump
a) Lay the appliance on the rear panel
b) Unclip tray spillage (as above)
c) Remove the electrical connection on
the circulation pump
d) Remove 2 clamps that are shown in the
picture (Heater casing- circulation
pump, sump-Circulation pump)
To Next Page
