Electrolux XBM20 - Machine Operation Controls; Protection Screen Operation; Bowl and Tool Fitting; Speed Control

• To ret:
- Line the shoes up with the slots in the screen crown.
- Press upwards and turn in an anti-clockwise direction (1
complete turn) until locked on the stop (binding spot).
Note: The screen stays in position on its own from the
start of turning.
THE BEATER CAN ONLY BE STARTED IF THE
SCREEN IS PROPERLY CLOSED AND LOCKED.
3.2 RAISING - LOWERING THE PROTECTION
SCREEN
To make cleaning easier, the rotating protection screen can be
removed and the plastic screen which covers.
• To remove it:
- Stop the machine, lower the cradle and remove the tool and
the bowl.
- With the screen locked, turn it in a clockwise direction (1
complete turn) until it is on the stop.
- The screen unhooks downwards and is released.
- The plastic screen can be removed by removing the wire screen
(for use without our).
THE BEATER CANNOT BE STARTED WHILE THE
SCREEN IS REMOVED.
3.3 FITTING THE BOWL AND THE TOOLS
• Proceed as follows:
- Lower the cradle to the down position, pushing the lever G
backwards.
- Put the tool inside the bowl.
Note: Make sure the handle rests are clean (see § 4-2).
- Present the bowl onto the cradle.
- Engage the bowl ball-and-socket in the cradle housing and
lower the bowl vertically to position the two cradle pins in the
handle holes.
- Slide the tool onto the tool-holder and twist it in an anti-clockwise
direction to lock it.
- Pull the lever G towards you to raise the bowl to the work
position.
- Close the protection screen.
- Press the START button.
3.3a
3.3b
3.4 CHANGING AND SELECTING SPEEDS
• The drive belt variable speed gives the user a continuous range
of speeds to carry out all sorts of work while giving highest output
and quality.
To change speeds, proceed as follows:
- Press the START button.
- Pull the lever towards you to decrease the speed and push it
away to increase it.
- Always start with a slow speed to prevent splashes or our
dust being given o󰀨 and then gradually increase the speed
bearing in mind that the drive force (torque) increases as the
speed decreases.
Never move the speed lever when stopped
Note:
The lever stays at the speed selected thanks to its any-po-
sition self-maintaining system.
- If the drive belt slips, decrease the speed.
- When the work is nished, bring the lever back to the slow
speed position, press the stop button and then lower the bowl
(see § 3-3).
• Speed for using the tools
V Speed at the planet gear (rpm)
A Hard dough
B Soft dough
Recommended work
3.4a
3.4b
3.5 MAXIMUM CAPACITIES
• The beater’s working capacity depends on:
- The tool used. ?
- The nature, quantity and density of the matter to be worked.
- The optimum speed for quality work.
• Too great a quantity will always be detrimental to the quality of
work and the service life of the beater’s mechanical components
and may lead to overheating of the motor and it stopping suddenly.
(see § 5-1).
Product Reference Bowl (L) Tool
10/20/30
Flour/water paste
( 60% Hydratation) Kg our 3/6/8
Pizza
(40% Hydratation) Kg dough 2,5/5/6
Short-crust pastry 2,5/5/6
Sweet pastry 2/4/5
Croissant dough
Kg our
2,5/5/6
Brioche dough 2,5/5/6
Chou pastry L. water 2/4/5
Meat Kg 5/10/15
Purée Kg potatoes 5/10/15
Fondant kg sugar 3/6/8
Egg whites 16/32/50
Genoese numbr of eggs 15/30/45
Biscuits 15/30/45
Meringues Kg sugar 0,75/1,5/2,5
Recommended maximum quantities
XBM20/30 GB 06 2015 4
3.2a
3.2b
3.2b
§5.3
