3.6 ACCESSORIES HUB
• Version A beaters are tted with an H12-type variable speed
drive take-o to power the following optional accessories:
- H 70 H and HV 82 H: Ø70 and Ø82 mm mincers, ENTERPRISE
or UNGER system. Supplied with hopper, pestle, knives and
discs.
- CX 21 H: Vegetable slicer tted with discs for cutting up to 8
mm, thin slicing, shredding, grating, etc.
- P 200 H: Food processor for purées, soups, compotes, sh
soups, etc. Supplied with 3 dierent grids.
• To install an accessory, proceed as follows:
- Fit the accessory depending on the work to be carried out.
Refer to the separate instructions for each accessory
machine.
3.6a
3.6b
3.6a
3.6a
The machine must be stopped in slow speed using the
stop button before tting or removing the accessory.
- Raise the cover H.
- Present the accessory B and introduce the cone C into the
beater hub A.
- Engage the male square section D into the hub A drive shaft,
turning B.
- Position the pin E opposite the housing I and push the acces-
sory rmly into hub A.
- Tighten the locking screw G (clockwise direction ) in the
recess F.
- Select the speed according to the accessory.
Note:
To remove the accessory, unscrew G a minimum of 4
turns to release from the recess F.
• Speeds to be used for the accessories:
VP = Accessory hub speed (rpm)
Recommended work
Cleaning and hygiene
4.1 IN-BETWEEN USE
• Remove the bowl and the tool
• Wash the inside of the bowl and the tool in a basin using hot
water with a disinfectant or de-greasing (if working with greasy
products) detergent added, then rinse with clean water and dry.
• Clean the planet gear holder, the tool-holder shaft and the pro-
tection screen using a damp sponge and a detergent / disinfectant
product, then rinse in clean water.
• Oil the accessory shaft (cooking oil or grease).
Note: Use cleaning products which are compatible with
aluminium parts.
4.2 AFTER USE
• Unplug the machine.
• Remove the bowl, tool and protection screen.
• Wash the bowl and the tools in a basin with a disinfectant or
de-greasing product, then rinse with clean water and dry. Only
the bowl can be cleaned in a dish-washer.
•
The full protection screen is not dishwasher-safe.
• Clean the planet gear holder, tool-holder shaft, protection
screen and cradle paying particular attention to the bowl edges
and where necessary the outside of the beater using a damp
sponge and a detergent / disinfectant product, then rinse.
• Oil the accessory shaft (cooking oil or grease).
• Check the various elements are properly clean.
Note: make sure that the cleaning products used are
compatible with the appliance element materials.
- Do not use abrasive detergents as these could scratch
the surfaces.
- To clean the accessory machines, refer to the instructions for
each accessory.
• Periodically: (at least once a month).
- Remove dust from the ventilation holes at the back of the
machine (a cause of overheating).
- Wipe and lightly oil the raising and lowering pillars with Va-
seline.
Never wash the machine with a pressure cleaner.
ATTENTION!!
Before dismantling any part, disconnect the appliance from the power supply.
Before using any cleaning product, be sure to read the instruction and safety instructions accompanying the product and use
appropriate protective equipment.
Do not clean the machine with a pressure cleaner
4.3 STRAY FLOUR PARTICLES:
In order to reduce the emission of stray our particles while loading
the bowl, it is recommended as follows:
- Empty the our bag or the container containing the our without
shaking it.
- Pour in the water before putting the our in if that is possible
- Always start at slow speed during the water/our mixing
- Do not shake an empty our bag. Roll it with care.
- The see-through plastic screen supplied with the machine must
be used.
Keeping to these simple rules will contribute to reducing the
emission of our dust and consequently reducing the risks of
allergy linked to that dust.
5 XBM20/30 GB 04 2019
