Electrolux XBM20 - Maintenance Procedures; Changing Drive Belt; Speed Adjustment; Planet Gear and Safety Checks

6.4 REMOVING THE PLANET GEAR
- Remove the protection screen and the cover after disconnecting
it.
- Remove the drive belt.
- Put a piece of wood between the bowl and the planet gear to
hold the planet gear.
- Remove the driven pulley and its key.
- Remove the accessories hub if the model has one.
- Remove the planet gear assembly by tapping it with a mallet
on the top of the sun gear shaft and lowering the bowl as
necessary.
6.2
6.4
6.5 CHECKING THE SAFETY DEVICES
• The correct operation of the safety devices should be checked
frequently. The motor should stop on opening the protection
screen and on lowering the bowl.
• If either of these functions does not occur:
- Do not use the machine.
- Have it adjusted by your dealer’s maintenance depart-
ment.
6.6 ELECTRICAL COMPONENTS
• Check the condition of the cable and electrical components
regularly.
6.7 ADDRESS FOR MAINTENANCE
In the rst instance, we advise you to contact the dealer who
sold you the machine.
· The manufacturer reserves the right to change and make im-
provements to its products without prior notice.
For any information or orders for spare parts,
state the type of machine, the serial number
and the electrical specications.
Dealer’s stamp
Date of purchase:
6.3 SPEED ADJUSTMENT
In normal operation, on changing from high speed to low speed,
the lever moves back slightly before locking in position.
• If this does not happen, carry out the following adjustment:
- Run the beater at slow speed (1) and stop it.
- Unscrew the speed change lever.
- Remove the cap to gain access to the mechanism and re-tighten
the lever.
- Release the anti-slip screw A lock-nut.
- Start the beater again and unscrew the anti-slip screw until the
lever is held at all speeds.
- Re-tighten the lock-nut.
- The beater is set in the factory to operate at approximately 35
to 180 rpm (planet gear speed).
7 XBM20/30 GB 09 2023
6.3
The machine must not operate if the bowl is
not in position on the cradle.
6.2 CHANGING THE DRIVE BELT
- Stop the beater in high speed (position 8) and unplug it.
- Remove the casing top cover retaining screws and disconnect
it to separate it from the head.
- Hold the drive belt by the sides and pull towards you until it is
released from the driven variable pulley.
- Then free it from the drive pulley.
- Lightly oil the motor shaft and variable pulley driven shafts with
Vaseline.
• To t the new drive belt:
- Present the drive belt to the drive pulley.
- Pull rmly to engage it as far as possible.
- Engage the drive pulley onto the driven pulley.
- Turn the driven pulley by hand to centre the drive belt.
6.2
