TC M Temperature Controller User Manual V1.08
Electron Dynamics Ltd page
9
V. Output
VI. Alarms
VII. Report
7.1 Pull Down Menus
7.1.1 File Menu
Save as defaults allows the user to save a copy of the current GUI set up, which can be loaded using the
load defaults command.
The exit command closes the GUI.
7.1.2 Port
The desired communication port can be chosen and the TCM Series Temperature Controller can be
connected or disconnected. Please note port needs to be selected and opened at the outset in order to
communicate with the controller.
7.1.3 Help
Displays help information
7.2 Control
7.2.1 Type
The control algorithm can be single or a combination of Proportional, Integral, Derivative terms. The list box
allows the user to define the controller terms required.
The available options are;
0. None
1. On/Off
2. Proportional
3. Proportional and Integral
4. Proportional, Integral and Derivative
User defined values can manually be entered here for the controller to operate from.
7.2.2 None
This is a default off mode for diagnostic or fail safe purposes.
7.2.3 On/Off
With On /off control the output drive is only fully On, heating or cooling or off.
