8. If desired, attach the plug protective cap to prevent
inadvertent removal of the power plug from the unit.
2-20
Focus
Wheel
Push to remove
9. If you wish to reorient the 9350BBA-C with the tripod
mount at the bottom and the focus wheel on top, simply
loosen knurled thumb screw located at the back side of
the chassis and rotate the 9350 assembly with respect to
video camera to the desired position.
Lockin
