19
9. SPECIFICATIONS
Name Brush cutter
Brushcutter Model
DCBT33D DCBT43D-1
Handle type Both hands
Machine weight 6.5Kg 7.5 Kg
Outward side 1760X610X420mm
Power transmission method Automatic centrifugal clutch spiral gear
Reduction rate 0.75 (15:20)
Blade rotating direction Counterclockwise (from operator′s view)
Model 1E36F 1E40F-5
Type Single cylinder air cooling 2-cycle
Displacement 33 cc 42.7cc
Max.Output 1.1Kw/7000r/min 1.4Kw/7000r/min
Max.Torque 1.6 N·m/5500r/min 2.2 N·m/6000r/min
Fuel tank capacity 0.8L
Fuel used Mixing rate 25:1
Lubricant oil FC2-Stroke engine oil
Carburetor Diaphragm Float piston valve
Sparking method IC-controled fly wheel magnet
Spark plug L7RTC
Starting mehtod Recoil starer
Stopping method Sparking circuit primary short(push button)
Gasoline
Engine
Net weight 3.5 Kg 3.9 Kg
*Specifications are subject to change without notice!
GUARANTEE
Refer to the enclosed guarantee conditions for the terms and conditions of guarantee.
ENVIRONMENT
Should your machine need replacement after extended use, do not put it in the domestic
waste but dispose of it in an environmentally safe way.
