OWNER MANUAL
3.4. Seat adjustment:
• Seat height: You can adjust seat height by releasing quick release lever and adjust seat height as needed.
Quick release lever
Adjust seat height
• Seat position: You can adjust seat position by unscrewing bottom hex bolt using 6 mm hex key and positioning the seat
in desired angle or/and length.
Hex bolt
3.5. Brakes adjustment:
Your Surface 604 is equipped with front and rear disc brakes. Proper alignment and adjustment of the brakes will provide
smooth and safe riding.
Surface 604 comes with brake calipers installed, however inspection and minor adjustments might be required.
Please follow instructions below for proper brakes adjustments.
• Check front /rear brakes by turning the wheels and squeezing right/left hand brake lever, - wheel should stop. If
the wheel doesn’t stop or brake pad grinding the disc brake – adjust the brakes as necessary.
Front Brakes
Inner pad adjuster
Inner pad adjuster
Brake arm Cable pinch bolt
Rear Brakes
Inner pad adjuster Barrel adjuster
Brake arm Cable pinch bolt
