Elenco Electronics AM/FM-108TK - Table of Contents; Parts List

-1-
The AM/FM Radio project is divided into two parts, the AM Radio Section and the FM Radio Section. At this time, only
identify the parts that you will need for the AM radio as listed below. DO NOT OPEN the bags listed for the FM radio. A
separate parts list will be shown for the FM radio after you have completed the AM radio.
PARTS LIST FOR THE AM RADIO SECTION
If you are a student, and any parts are missing or damaged, please see instructor or bookstore. If you purchased this kit
f
rom a distributor, catalog, etc., please contact Elenco
®
E
lectronics (address/phone/e-mail is at the back of this manual) for
additional assistance, if needed. DO NOT contact your place of purchase as they will not be able to help you.
RESISTORS
Qty. Symbol Value Color Code Part #
1 R46 47Ω 5% 1/4W yellow-violet-black-gold 124700
4 R38, 43, 48, 49 100Ω 5% 1/4W brown-black-brown-gold 131000
1 R47 330Ω 5% 1/4W orange-orange-brown-gold 133300
1 R41 470Ω 5% 1/4W yellow-violet-brown-gold 134700
1 R37 1kΩ 5% 1/4W brown-black-red-gold 141000
1 R42 2.2kΩ 5% 1/4W red-red-red-gold 142200
3 R33, 36, 44 3.3kΩ 5% 1/4W orange-orange-red-gold 143300
1 R40 10kΩ 5% 1/4W brown-black-orange-gold 151000
1 R32 12kΩ 5% 1/4W brown-red-orange-gold 151200
1 R35 27kΩ 5% 1/4W red-violet-orange-gold 152700
1 R39 39kΩ 5% 1/4W orange-white-orange-gold 153900
1 R31 56kΩ 5% 1/4W green-blue-orange-gold 155600
1 R45 470kΩ 5% 1/4W yellow-violet-yellow-gold 164700
1 R34 1MΩ 5% 1/4W brown-black-green-gold 171000
1 Volume/S2 50kΩ / SW Pot/SW with nut and washer 192522
CAPACITORS
Qty. Symbol
Value
Description
Part #
1 C30 150pF Discap (151) 221510
1 C44 .001µF Discap (102) 231036
2 C31, 38 .01
µF Discap (103) 241031
5 C29, 33, 35, 36, 37 .02µF or .022µF Discap (203) or (223) 242010
1 C28 .1µF Discap (104) 251010
3 C32, 40, 41 10
µF Electrolytic Radial (Lytic) 271045
1 C42 47µF Electrolytic Radial (Lytic) 274744
1 C34 100µF Electrolytic Radial (Lytic) 281044
2 C39, 43 470
µF Electrolytic Radial (Lytic) 284744
1 C1 Variable Tuning Gang AM/FM 299904
SEMICONDUCTORS
Qty. Symbol Value Description Part #
2 D4, 5 1N4148 Diode 314148
5 Q7, 8, 9, 10, 11
2N3904 Transistor NPN 323904
1 Q12 2N3906 Transistor PNP 323906
1
Q14 MPS6560 or 8050 Transistor NPN 328050
1 Q13 MPS6562 or 8550 Transistor PNP 328550
COILS MAGIC WAND
Qty
.
Symbol
Color Description Part # Qty. Description Part #
1 L5 Red AM Oscillator 430057 1 Iron Core 461000
1 T6 Yellow AM IF 430260 1 Brass Core 661150
1
T7
White AM IF 430262 4” Shrink Tubing 890120
1 T8 Black AM IF 430264
1 L4 AM Antenna with Holders 484004
MISCELLANEOUS
**** SA
VE
THE BOX
THA
T THIS KIT CAME IN. IT WILL BE USED ON PAGES 24 & 53. ****
Qty
.
Description Part #
1 PC Board 517054
1 Switch 541023
1
Battery Holder 590096
1 Speaker 590102
1 Knob (pot) 622017
1
Knob (dial) 622030
1 Earphone Jack with Nut 622130 or 622131
1 Radio Stand 626100
1
Earphone 629250
Qty
.
Description Part #
3 Screw 2-56 x 1/4” 641230
3 Screw M2.5 641310
3
Nut 2-56 644201
1 Plastic Washer 645108
8 Test Point Pin 665008
1
Label AM/FM 723508
1 Speaker Pad 780128
6” Wire 22 insulated 814520
1
Solder 9ST4
