4
Mixed Up Music
Snappy says there sure are a lot of
different sounds that can be made
with the music and alarm ICs.
In the circuit, the outputs from the alarm and
music ICs are connected together. Build the
circuit shown and then place the alarm IC (U2)
directly over the music IC (U1), resting on two
1-snaps and a 2-snap. Turn on the switch (S1)
and you will hear a siren and music together
while the lamp (L1) varies in brightness.
Modify the last circuit by connecting points Y & Z with a 2-snap (on
level 5). The circuit works the same way but now it sounds like a
machine gun with music.
Project 64 Blaster Disaster
Now remove the 2-snap connection between Y & Z and then make
a 2-snap connection between X & Y (on level 5). The circuit works
the same way but now it sounds like a re engine with music.
Project 65 Siren & Song
Now remove the 2-snap connection between X & Y and then make
a 2-snap connection between W & X (on level 5). The circuit works
the same way but now it sounds like an ambulance with music.
Project 66 Ambulance Song
Project 63
