Eleris EM303B - F2 Group: Input;Output Terminal Parameters

User Manual
EM303B General Purpose Inverter
56
No.
Function
Range
Unit
Default
Type
S/N
F1-25
Analog Input Gain K4
0.00~600.00
%
0.00
●
57
F1-26
Analog Input Gain K5
0.00~600.00
%
0.00
●
58
F1-27
Analog Input Gain K6
0.00~600.00
%
0.00
●
59
F1-28
Analog Input Gain K7
0.00~600.00
%
0.00
●
60
F1-29
Analog Input Gain K8
0.00~600.00
%
0.00
●
61
F1-30
Communication Overtime
0.0~60.0（0.0: Disabled）
S
0.0
●
62
F1-31
Master Communication
Transmitting Data
0: Input frequency
1: Output frequency
2: Primary Numeric Frequency
3: Auxiliary Numeric Frequency
4: VP
5: VS
6: VF
7: IS
8: IF
0
●
63
6.2.3 F2 Group: Input/Output Terminal Parameters
No.
Function
Range
Unit
Default
Type
S/N
F2-00
Multi-function Input Terminal X1-RUN
See Table 6-1
Functions of Numeric
Multi-function Input
Terminals
1
〇
64
F2-01
Multi-function Input Terminal X2-F/R
2
〇
65
F2-02
Multi-function Input Terminal X3-D1
3
〇
66
F2-03
Multi-function Input Terminal X4-D2
4
〇
67
F2-04
Multi-function Input Terminal X5-D3
5
〇
68
F2-05
Multi-function Input Terminal X6-FRS
9
〇
69
F2-06
Multi-function Input Terminal X7-RST
10
〇
70
F2-07
Not used
71
F2-08
VS Input Function Defining
0
〇
72
F2-09
IS Input Function Defining
0
〇
73
F2-10
VF Input Function Defining
0
〇
74
F2-11
IF Input Function Defining
0
〇
75
F2-12
Multi-function Output Terminal Y1
See Table 6-2
Functions of Numeric
Multi-function Output
Terminals
0
〇
76
F2-13
Multi-function Output Terminal Y2
1
〇
78
F2-14
Relay Output Terminal R1
9
〇
79
F2-15
Not Used
80
F2-16
Analog Output Terminal M0
See Table 6-3 F2-16~F2-17
Analog Output Full Scale
%
0
〇
81
F2-17
Analog Output Terminal M1
%
6
〇
82
F2-18
~F2-21
Not Used
83
~86
F2-22
M0 Output Lower Limit
0.00～100.00
%
0.00
●
87
F2-23
M0 Output Upper Limit
0.00～100.00
%
100.00
●
88
F2-24
M0 Output Gain
0.00～300.00
%
95.00
●
89
F2-25
M1 Output Lower Limit
0.00～100.00
%
0.00
●
90
