Eleris EM303B - F9 Group: Speed Setting Options

User Manual
EM303B General Purpose Inverter
71
F8-27
Output Bias 2_3
0.00～100.00,100.00=Fmax
%
100.00
●
283
F8-28
Input Bias 2_0
0.00~ Input Bias 2_1
%
0.50
●
284
F8-29
Input Bias 2_1
Input Bias 2_0~ Input Bias 2_2
%
25.00
●
285
F8-30
Input Bias 2_2
Input Bias 2_1~ Input Bias 2_3
%
75.00
●
286
F8-31
Input Bias 2_3
Input Bias 2_2~100.00
%
100.00
●
287
7.1.5 F9 Group: Speed Setting Options
No.
Function
Range
Unit
Default
Type
S/N
F9-00
Not Used
288
F9-01
Parameter Editing Mode
0:Editable through keypad and RS485
1:Editable through keypad
0
〇
289
F9-02
Numeric Input Control
Mode
Ones place: Numeric reference input
control mode
0: Auto-save the change in RAM
(Press DATA/ENTER to save)
1: Auto-save the change in EEPROM
(Memory function at power failure)
Tens place: Not used
Hundreds place: Not used
Thousands place:
Terminal UP/DOWN rate control
0: Automatic rate control
1: Correspond to the setting UP/DOWN
rate
Ten thousands place: Not Used
1000
〇
290
F9-03
Speed Setting Mode
Ones place: Integrated speed input mode
0: Primary speed setting mode
1: Auxiliary speed setting mode
2:Primary speed setting mode + auxiliary
speed setting mode
Tens place:
Speed setting mode under jog control
0: Jog numeric speed setting mode
1: Jog numeric speed setting mode +
primary speed setting mode
2: Jog numeric speed setting mode +
auxiliary speed setting mode
Hundreds place: Relation between
auxiliary speed and primary speed
0: Primary speed + auxiliary speed
1: Primary speed - auxiliary speed
000
〇
291
F9-04
Special Speed Setting Mode
0: Program Operation
1: Wobbulation Mode
2: Stepping Mode 0
3: Stepping Mode 1
0
〇
292
