User Manual
EM303B General Purpose Inverter
72
4: Stepping Mode 2
5: Stepping Mode 3
6: Stepping Mode 4
7: Stepping Mode 5
F9-05
Auxiliary Speed Setting
Mode
0: Auxiliary numeric frequency
1: VP
2: VS
3: IS
4: Not Used
5: K3*VS+K4*IS
6: K3*VS+K5*VF
7: K4*IS+K6*IF
8: MAX{K3*VS,K5*VF}
9: MAX{K4*IS,K6*IF}
10: K1*VP+K2*(K3*VS+K4*IS
+K5*VF+K6*IF-K8*5V)
0
〇
293
F9-06
Auxiliary Numeric
Frequency Setting
0.00～Fmax/0.0～Fmax
Hz
0.00
●
294
F9-07
UP/DOWN Frequency Rate
0.00～100.00/0.0～100.0
Hz/S
1.00
●
295
F9-08
Regular Speed Setting
Mode
Special Speed Setting Mode
Auxiliary Speed Setting
Mode
Process PID Output
Ones place:
Regular speed setting mode options
0: Regular frequency input
1: VS* Regular frequency input
2: VF* Regular frequency input
3: IS* Regular frequency input
4: IF* Regular frequency input
Tens place:
Special speed setting mode options
0: Special frequency input
1: VS* Special frequency input
2: VF* Special frequency input
3: IS* Special frequency input
4: IF* Special frequency input
Hundreds place:
Auxiliary speed setting mode options
0: Auxiliary frequency input
1: VS* Auxiliary frequency input
2: VF* Auxiliary frequency input
3: IS* Auxiliary frequency input
4: IF* Auxiliary frequency input
Thousands place：
Process PID Output mode options
0: PID output
1: VS* PID output
2: VF* PID output
0000
〇
296
