Installation
4.2 Electrical connection
WARNING
Damage to the device due to faulty electrical connection.
• The device must be operated with the correct connection voltage (see type
plate).
WARNING
Damage to the device from the use of a non-fitting or unsuitable drive control
unit.
• The control unit must support all the options attached to the device.
• Connect all the marked cable conductors.
• Insulate unmarked cores/cables.
WARNING
Damage or destruction of the device due to faulty electrical connection.
• The device must not be operated without an overcurrent shut-off.
• The device must be shut off by an overcurrent shut-off when it reaches the
limit positions. The overcurrent shut-off is optionally available as an internal
or external model.
• The customer-provided power supply must be capable of making at least the
minimum amount of current available to each device (see section 4.2.2). If
this current is not supplied, the device cannot be shut off when it reaches the
limit positions.
• Ifacongurationofthedevicewithoutelectronicshasbeenselected,the
overcurrent shut-off must be implemented externally by the customer.
WARNING
Damage or destruction of the device through ingress of moisture in the connec-
tion cables.
• For devices with protection type IP 65, the customer-provided connection of
the cable ends or connectors must also have IP 65 protection.
